Rapid rise to operating temperature and low oscillation aids high process throughput at low scrap rates. The industry leading Eurotherm PID algorithm delivers fast reacting and repeatable control and has been enhanced for EPC3000 to further reduce overshoot. Recalibration and user calibration correction functions are available to further improve accuracy. The EPC3000 range of programmable single loop process and temperature controllers maximizes efficiency and repeatability and is certified for cyber security communications robustnessĪccuracy and repeatability Process inputs are fast and accurate, with exceptional thermal stability, aiding precise and consistent control over long periods without calibration drift. This enables a dual loop 3500 to be used to control both carbon potential and temperature in an atmosphere controlled furnace.EPC3000 Helping deliver an efficient and secure process The 3500 calculates carbon potential from measuring both the oxygen concentration and temperature of a furnace using a zirconia probe. A total of sixteen module types, including relay, logic, triac and analogue, are available to fit into either three slots on 3508 or six slots on 3504. 50 programs with up to two channels can be stored with a total of 500 segments.Ī range of plug-in I/O modules caters for individual application requirements minimising stock and spares holding. The dual loop 3500 has two programmers which can be configured as synchronized or independent programs. Heat treatment and other processes often require the ability to change setpoints with time. The loops may also be ‘soft’ wired together in creative ways to create cascade, ratio or other intelligent control strategies. Two independent PID loops make the 3500 ideal for interactive processes such as those found in carburizing furnaces, environmental chambers and autoclaves. OEM security enables a user to protect their intellectual property by preventing unauthorized cloning of configuration. A four-line message centre provides custom or standard views of important information to the user, while vertical and horizontal bar graphs provide visual indication of the process at a glance.
The large, 5-digit display provides a clear and unambiguous indication of the process value.
Ethernet cable for eurotherm itools Pc#
More advanced features are configured using a PC based graphical configuration tool - enabling users to pick function blocks from a library then connect them together using soft wiring. This includes input sensor type, measurement range, control options and alarms - making 'Out of the Box' operation truly achievable.
Ethernet cable for eurotherm itools code#
A simple 'QuickStart' code is used to configure all the basic functions essential to controlling your process. With an emphasis on flexibility, 3500 controllers still maintain ease of use. Specialist function blocks, recipe selection, setpoint programmers, math, logic, timer functions and flexible communication options are just a few examples of what makes these instruments a key part of a total process solution. They provide flexible I/O options to control and measure a multitude of processes - temperature, carbon potential, humidity, flow, pressure, level, viscosity, additive dosing and many more. The 3504 offers much more than temperature control - advanced features and options make them capable of small machine control. Simple and intuitive operation with customizable displaysįlexible setpoint programming with dual channel capability - up to 50 time based programsĪdvanced features providing custom solutions and small machine controllers
Graphical wiring editor for easy creation of advanced, flexible solutionsĮasy system integration - Modbus RTU, Modbus TCP, Profibus and DeviceNetTM network Protocols Precision PV measurement combined with high performance control - yielding consistently high product qualityįlexible, modular units - up to 6 I/O slots with 16 different module types ***Please note that the model number is made up as follows:*** 3504/Function/Supply Voltage/Loops/Application/Programs/Recipes/ToolkitWires/G/ Output1/Output2/Output3/Output4/Output5/Output6/HComms/JComms/xx/ENG/ENGĭual loop control - ideal for processes with two interactive variables *NOTE: Click here For information on the USB cable offered in the communications option We highly recommend that customers also purchase the Eurotherm USB CPI Clip or the Eurotherm IR Clip for easier configuration with iTools Software.
*NOTE: This is an UNCONFIGURED 3504 Temperature Controller.
